Servo Roll Feeds

EQUIPMENT & SYSTEMS

ServoMatic© VII - Servo Roll Feeds


CoilMate/Dickerman Products of Cooper-Weymouth, Peterson

ServoMatic© VII - Servo Roll Feed LogoServoMatic© VII 6" and 12" servo feeds offer greater performance at a value-driven price. The ServoMatic© VII provides quick adjustments with no tools, closed loop accuracy and long-lift dependability with precision gear drive and high performance brushless servo motor.
ServoMatic© VII - Servo Roll Feed

Standard Features:

  • • 500-job memory
  • • Remote jog
  • • Solenoid operated dual cylinder control lift
  • • In-motion feed length refinement
  • • Jog-to-length and inch/metric selection capability
  • • Two-Year Warranty

Optional:

  • • Mechanical roll lift (Model SMVI11 High Speed)
  • • Spanish language display
  • • Programmable Pattern
  • • High Speed Drive Packages (up to 400 SPM)
  • • High Speed Single Cylinder Roll Lift (400 SPM)
  • • Press Mounting Bracket
  • • Encoder Tracking Wheel
  • • Pull-Thru Stock and Wire Straighteners

Specifications

Servo Feeds Model Width Thickness Feed Length
ServoMatic VII6
(Pneumatic Roll Lift)		 SMVII6 6" (152.400mm) .125" (3.175mm) 999.999" (25.39m)
ServoMatic VII12
(Pneumatic Roll Lift)		 SMVII12 12" (304.800mm) .078" (1.981mm) 999.999" (25.39m)
ServoMatic© VII11
(Pneumatic Roll Lift) 		SMVII11 11" (279.400mm) .078" (1.981mm) 999.999" (25.39m)


ServoMatic VII High Speed ServoFeeder
SMVII06 Servofeed with High Speed Pneumatic roll lift and single point lubrication
ServoMatic VII High Speed Servo Feed
SMVII12 Servofeed with High Speed Drive Package and Single Cylinder Roll Lift Capable of 400 SPM Production Speeds
Push-Pull Servo Feeds are ideal for thin, delicate materials such as Aluminum Foil or various gasket materials. A single control with a Programmable Offset Feature allows the material to be Pushed into the die and Pulled out simultaneously to eliminate buckling.
Push-Pull Servo Feeds are ideal for thin, delicate materials such as Aluminum Foil or various gasket materials. A single control with a Programmable Offset Feature allows the material to be Pushed into the die and Pulled out simultaneously to eliminate buckling.
ServoFeed with encoder tracking wheel
ServoMatic© Servofeed with encoder tracking wheel
